Slotted L-Foot Mounting Bases
Slotted L-foot mounting bases create an L-shaped interface between a mounting surface and support member. They are shown as an L-shaped bracket with elongated fixing slots and different upright heights pictured. They are used for rail mounting foot connections and adjustable support interfaces. Bracket height, base length, slot dimensions, material, and finish are confirmed with the selected product drawing or quotation.
L-shaped bracket
Elongated fixing slots
Different upright heights pictured
Catalog reference: JS-024
01 / PRODUCT DETAILS
Features & configuration
Slotted L-foot mounting bases create an L-shaped interface between a mounting surface and support member. They are shown as an L-shaped bracket with elongated fixing slots and different upright heights pictured. They are used for rail mounting foot connections and adjustable support interfaces. Bracket height, base length, slot dimensions, material, and finish are confirmed with the selected product drawing or quotation. The reference images show the available product form. Match the connection geometry and specified material to your project before ordering.
- L-shaped bracket.
- Elongated fixing slots.
- Different upright heights pictured.
02 / TECHNICAL INFORMATION
Specifications
| Product type | Slotted L-Foot Mounting Bases |
| Bracket height | Confirm with the selected product drawing or quotation |
| Base length | Confirm with the selected product drawing or quotation |
| Slot dimensions | Confirm with the selected product drawing or quotation |
| Material and finish | Confirm with the selected product drawing or quotation |
Numerical dimensions and performance ratings are not specified in the supplied product record. Confirm the listed requirements against a quotation and approved drawing.
03 / PROJECT FIT
Applications
Rail mounting foot connections
Adjustable support interfaces
Application guidance describes the component's typical role. Suitability depends on the complete system design, mating parts and project requirements.
