Hot-Dip Galvanized Flat Washers
JINSHANG hot-dip galvanized flat washers have a flat circular form with a central clearance hole. They provide a flat bearing surface beneath a compatible nut or bolt head and are used in mounting bolt assemblies or specified load-spreading washer positions. Surface finish is hot-dip galvanized, with coating specification to be confirmed. Inside diameter, outside diameter, thickness, material, and coating are confirmed with the selected product drawing or quotation.
Flat circular form
Central clearance hole
Hot-dip galvanized designation
Catalog reference: JS-055
01 / PRODUCT DETAILS
Features & configuration
JINSHANG hot-dip galvanized flat washers have a flat circular form with a central clearance hole. They provide a flat bearing surface beneath a compatible nut or bolt head and are used in mounting bolt assemblies or specified load-spreading washer positions. Surface finish is hot-dip galvanized, with coating specification to be confirmed. Inside diameter, outside diameter, thickness, material, and coating are confirmed with the selected product drawing or quotation. The reference images show the available product form. Match the connection geometry and specified material to your project before ordering.
- Flat circular form.
- Central clearance hole.
- Hot-dip galvanized designation.
02 / TECHNICAL INFORMATION
Specifications
| Product type | Hot-Dip Galvanized Flat Washers |
| Surface finish | Hot-dip galvanized; coating specification to be confirmed |
| Inside diameter | Confirm with the selected product drawing or quotation |
| Outside diameter | Confirm with the selected product drawing or quotation |
| Thickness | Confirm with the selected product drawing or quotation |
| Material and coating | Confirm with the selected product drawing or quotation |
Numerical dimensions and performance ratings are not specified in the supplied product record. Confirm the listed requirements against a quotation and approved drawing.
03 / PROJECT FIT
Applications
Mounting bolt assemblies
Specified load-spreading washer positions
Application guidance describes the component's typical role. Suitability depends on the complete system design, mating parts and project requirements.
04 / PRODUCT PHOTOGRAPHY
